point_m2ae

Point-M2AE classification, segmentation, and masked autoencoder pretraining models.

First page of Point-M2AE: Multi-scale Masked Autoencoders for Hierarchical Point Cloud Pre-training

2205.14401 · May 2022

Classes:

EncoderBlock –

A stack of transformer blocks that adds the positional embedding before every block.
ConvResBlock1d –

A residual block used by the pre-training feature-propagation extraction.
FeaturePropagation –

Interpolate features from a coarse set to a fine set, fuse and refine them.
HierarchicalEncoder –

Multi-scale hierarchical transformer encoder of Point-M2AE.
PointM2AEClassification –

Implementation of the Point-M2AE classification model.
PointM2AEPartSegmentation –

Implementation of the Point-M2AE part-segmentation model.
PointM2AEPretraining –

Implementation of the Point-M2AE pre-training model.
HierarchicalEncoderMAE –

Hierarchical encoder variant used for pre-training, with multi-scale back-propagated masking.

Functions:

local_attention_mask –

Convert a boolean neighbor mask into the additive pre-softmax bias of the shared attention.
local_att_mask –

Compute the boolean local-attention mask of a center set from a pairwise-distance threshold.
dense_centers_to_packed –

Flatten a densified center set \((B, G, 3)\) into packed coordinates and a batch index.
multi_scale_group –

Build the multi-scale grouping by repeatedly applying FPS + KNN on the previous-stage centers.

EncoderBlock [source] ¶

EncoderBlock(
    embed_dim: int,
    depth: int,
    num_heads: int,
    mlp_ratio: float = 4.0,
    qkv_bias: bool = False,
    dropout: float = 0.0,
    attn_drop_rate: float = 0.0,
    drop_path: Union[float, List[float]] = 0.0,
    act: Union[str, Callable, None] = "gelu",
    norm: Union[str, Callable, None] = LayerNorm,
)

Bases: Module

A stack of transformer blocks that adds the positional embedding before every block.

Parameters:

embed_dim (int) –

The number of channels.
depth (int) –

The number of transformer blocks.
num_heads (int) –

The number of attention heads.
mlp_ratio (float, default: 4.0 ) –

The feed-forward expansion ratio.
qkv_bias (bool, default: False ) –

Whether to add a bias to the query / key / value projection.
dropout (float, default: 0.0 ) –

The dropout rate for the MLP and attention output projections.
attn_drop_rate (float, default: 0.0 ) –

The attention dropout rate.
drop_path (Union[float, List[float]], default: 0.0 ) –

The stochastic depth rate, either a scalar or a per-block list.
act (Union[str, Callable, None], default: 'gelu' ) –

The activation function used in the feed-forward MLP.
norm (Union[str, Callable, None], default: LayerNorm ) –

The normalization applied before attention and the MLP.

Shape

Input: \((B, N, C)\)
Output: \((B, N, C)\)

ConvResBlock1d [source] ¶

ConvResBlock1d(
    channels: int,
    act: Union[str, Callable, None] = "gelu",
    act_kwargs: Optional[Dict[str, Any]] = None,
    norm: Union[str, Callable, None] = "batch_norm",
    norm_kwargs: Optional[Dict[str, Any]] = None,
)

Bases: Module

A residual block used by the pre-training feature-propagation extraction.

Computes \(\text{act}(W_2(\text{act}(W_1 x)) + x)\) where each linear layer is followed by a normalization. The residual addition prevents expressing this as a single plain-last MLP, so the inner net1 (linear -> norm -> act) and net2 (linear -> norm) chains are built as MLP and the residual add is kept in forward. A shared \(1 \times 1\) convolution over \((B, C, N)\) is equivalent to a MLP over the flattened feature dim.

Parameters:

channels (int) –

The number of input and output channels.
act (Union[str, Callable, None], default: 'gelu' ) –

The activation function.
act_kwargs (Optional[Dict[str, Any]], default: None ) –

Extra keyword arguments for the activation.
norm (Union[str, Callable, None], default: 'batch_norm' ) –

The normalization function.
norm_kwargs (Optional[Dict[str, Any]], default: None ) –

Extra keyword arguments for the normalization.

Shape

Input: \((B \cdot N, C)\)
Output: \((B \cdot N, C)\)

FeaturePropagation [source] ¶

FeaturePropagation(
    in_channels: int,
    out_channels: int,
    blocks: int = 1,
    act: Union[str, Callable, None] = "gelu",
    act_kwargs: Optional[Dict[str, Any]] = None,
    norm: Union[str, Callable, None] = "batch_norm",
    norm_kwargs: Optional[Dict[str, Any]] = None,
)

Bases: Module

Interpolate features from a coarse set to a fine set, fuse and refine them.

Each fine point gathers the three nearest coarse points with the shared packed PointNet2FeaturePropagation interpolation, optionally concatenates the fine features, then applies a fuse MLP and a residual extraction stack. Used by the pre-training decoder. The interpolation matches the reference inverse-distance-squared weighting (\(1 / (d^2 + 10^{-8})\)) up to the \(\sim 10^{-6}\) difference between the direct \(\lVert a - b \rVert^2\) distance and the reference algebraic expansion.

Parameters:

in_channels (int) –

The number of input channels (fine + coarse features).
out_channels (int) –

The number of output channels.
blocks (int, default: 1 ) –

The number of residual blocks in the extraction stack.
act (Union[str, Callable, None], default: 'gelu' ) –

The activation function.
act_kwargs (Optional[Dict[str, Any]], default: None ) –

Extra keyword arguments for the activation.
norm (Union[str, Callable, None], default: 'batch_norm' ) –

The normalization function.
norm_kwargs (Optional[Dict[str, Any]], default: None ) –

Extra keyword arguments for the normalization.

Shape

centers_fine: \((B, N, 3)\)
centers_coarse: \((B, S, 3)\)
points1: \((B, N, C_1)\) or None
points2: \((B, S, C_2)\)
Output: \((B, N, C_\text{out})\)

HierarchicalEncoder [source] ¶

HierarchicalEncoder(
    encoder_depths: Sequence[int],
    encoder_dims: Sequence[int],
    local_radius: Sequence[float],
    num_heads: int,
    drop_path: float = 0.1,
    with_norms: bool = True,
    in_channels: int = 0,
    token_local_channels: Sequence[int] = (128, 256),
    token_global_channels: Sequence[int] = (512,),
    act: Union[str, Callable, None] = "relu",
    act_kwargs: Optional[Dict[str, Any]] = None,
    norm: Union[str, Callable, None] = "batch_norm",
    norm_kwargs: Optional[Dict[str, Any]] = None,
)

Bases: Module

Multi-scale hierarchical transformer encoder of Point-M2AE.

Each stage embeds (or merges) tokens, computes a local-attention mask from the stage centers and runs a transformer block stack. The forward pass operates on the visible (unmasked) tokens; in eval mode no masking is applied. The encoder consumes the precomputed multi-scale grouping (neighborhoods, centers and neighbor indices) so the same grouping can be shared with the decoder.

Parameters:

encoder_depths (Sequence[int]) –

The number of transformer blocks per stage.
encoder_dims (Sequence[int]) –

The channel width per stage.
local_radius (Sequence[float]) –

The local-attention radius per stage (non-positive disables the mask).
num_heads (int) –

The number of attention heads.
drop_path (float, default: 0.1 ) –

The maximum stochastic depth rate (linearly scaled across blocks).
with_norms (bool, default: True ) –

Whether to apply a per-stage output LayerNorm (disabled for the ModelNet40 / ScanObjectNN finetune heads).
in_channels (int, default: 0 ) –

The number of per-point feature channels concatenated to the coordinates at the first stage (\(0\) for coordinates only).
token_local_channels (Sequence[int], default: (128, 256) ) –

Hidden widths of the first-stage token embedder's per-point MLP (later stages derive their widths from encoder_dims).
token_global_channels (Sequence[int], default: (512,) ) –

Hidden widths of the first-stage token embedder's per-group MLP.
act (Union[str, Callable, None], default: 'relu' ) –

The activation function used in the token embedders and transformer blocks.
act_kwargs (Optional[Dict[str, Any]], default: None ) –

Extra keyword arguments for the activation.
norm (Union[str, Callable, None], default: 'batch_norm' ) –

The normalization function used in the token embedders.
norm_kwargs (Optional[Dict[str, Any]], default: None ) –

Extra keyword arguments for the normalization.

PointM2AEClassification [source] ¶

PointM2AEClassification(
    in_channels: int,
    num_classes: int,
    *,
    group_sizes: Sequence[int] = (16, 8, 8),
    num_groups: Sequence[int] = (512, 256, 64),
    encoder_depths: Sequence[int] = (5, 5, 5),
    encoder_dims: Sequence[int] = (96, 192, 384),
    token_local_channels: Sequence[int] = (128, 256),
    token_global_channels: Sequence[int] = (512,),
    local_radius: Sequence[float] = (0.32, 0.64, 1.28),
    num_heads: int = 6,
    drop_path: float = 0.1,
    concat_pooling: bool = False,
    dropout: float = 0.5,
    head_channels: Sequence[int] = (256, 256),
)

Bases: ClassificationModel

Implementation of the Point-M2AE classification model.

Point-M2AE: Multi-scale Masked Autoencoders for Hierarchical Point Cloud Pre-training. This implementation is adapted from the official repository ZrrSkywalker/Point-M2AE.

The model groups the input cloud at multiple scales, encodes it with the hierarchical transformer encoder and pools the finest-stage tokens into a feature passed to an MLP head. The pooling matches the reference: ModelNet40 sums the token mean and max, while ScanObjectNN concatenates the mean over all tokens with the max over the tokens after the first one.

Parameters:

in_channels (int) –

The number of per-point feature channels concatenated to the coordinates (\(0\) for coordinates only).
num_classes (int) –

The number of output classes.
group_sizes (Sequence[int], default: (16, 8, 8) ) –

The neighborhood size per stage.
num_groups (Sequence[int], default: (512, 256, 64) ) –

The number of centers per stage.
encoder_depths (Sequence[int], default: (5, 5, 5) ) –

The number of transformer blocks per stage.
encoder_dims (Sequence[int], default: (96, 192, 384) ) –

The channel width per stage.
token_local_channels (Sequence[int], default: (128, 256) ) –

Hidden widths of the first-stage token embedder's per-point MLP.
token_global_channels (Sequence[int], default: (512,) ) –

Hidden widths of the first-stage token embedder's per-group MLP.
local_radius (Sequence[float], default: (0.32, 0.64, 1.28) ) –

The local-attention radius per stage.
num_heads (int, default: 6 ) –

The number of attention heads.
drop_path (float, default: 0.1 ) –

The maximum stochastic depth rate.
concat_pooling (bool, default: False ) –

Use the ScanObjectNN concat pooling when True, the ModelNet40 sum pooling otherwise.
dropout (float, default: 0.5 ) –

The dropout rate in the classification head.
head_channels (Sequence[int], default: (256, 256) ) –

The hidden widths of the classification head.

Shape

pos: \((N, 3)\)
batch: \((N,)\)
Output: \((B, C)\) where \(C\) is the number of classes.

Methods:

configure_h_encoder –

Build the hierarchical transformer encoder.

Attributes:

num_features (int) –

Channel count \(C\) of the pooled features entering the head.

num_features `property` ¶

num_features: int

Channel count \(C\) of the pooled features entering the head.

configure_h_encoder [source] ¶

configure_h_encoder() -> HierarchicalEncoder

Build the hierarchical transformer encoder.

PointM2AEPartSegmentation [source] ¶

PointM2AEPartSegmentation(
    in_channels: int,
    num_classes: int,
    *,
    num_categories: int = 16,
    group_sizes: Sequence[int] = (16, 8, 8),
    num_groups: Sequence[int] = (512, 256, 64),
    encoder_depths: Sequence[int] = (5, 5, 5),
    encoder_dims: Sequence[int] = (96, 192, 384),
    token_local_channels: Sequence[int] = (128, 256),
    token_global_channels: Sequence[int] = (512,),
    local_radius: Sequence[float] = (0.32, 0.64, 1.28),
    num_heads: int = 6,
)

Bases: PartSegmentationModel

Implementation of the Point-M2AE part-segmentation model.

Point-M2AE: Multi-scale Masked Autoencoders for Hierarchical Point Cloud Pre-training. This implementation is adapted from the official repository ZrrSkywalker/Point-M2AE.

Per-stage encoder features are propagated back to the full-resolution cloud, concatenated with a global feature and the one-hot object label, and decoded into per-point logits. Every sample in the packed batch must contain the same number of points; a ragged batch raises ValueError.

Parameters:

in_channels (int) –

The number of per-point feature channels concatenated to the coordinates (\(0\) for coordinates only).
num_classes (int) –

The number of part-segmentation classes.
num_categories (int, default: 16 ) –

The number of object categories (for the one-hot label embedding).
group_sizes (Sequence[int], default: (16, 8, 8) ) –

The neighborhood size per stage.
num_groups (Sequence[int], default: (512, 256, 64) ) –

The number of centers per stage.
encoder_depths (Sequence[int], default: (5, 5, 5) ) –

The number of transformer blocks per stage.
encoder_dims (Sequence[int], default: (96, 192, 384) ) –

The channel width per stage.
token_local_channels (Sequence[int], default: (128, 256) ) –

Hidden widths of the first-stage token embedder's per-point MLP.
token_global_channels (Sequence[int], default: (512,) ) –

Hidden widths of the first-stage token embedder's per-group MLP.
local_radius (Sequence[float], default: (0.32, 0.64, 1.28) ) –

The local-attention radius per stage.
num_heads (int, default: 6 ) –

The number of attention heads.

Shape

pos: \((N, 3)\)
batch: \((N,)\)
category: \((B, \text{num\_categories})\) one-hot object label
Output: \((N, C)\) where \(C\) is the number of part classes.

Methods:

configure_h_encoder –

Build the hierarchical transformer encoder with per-stage output norms.
configure_label_conv –

Build the MLP embedding the category one-hot for the global branch.
configure_propagations –

Build the per-stage feature-propagation modules interpolating stage features to every point.

Attributes:

num_features (int) –

Feature dimension \(C\) of the features entering the head.

num_features `property` ¶

num_features: int

Feature dimension \(C\) of the features entering the head.

configure_h_encoder [source] ¶

configure_h_encoder() -> HierarchicalEncoder

Build the hierarchical transformer encoder with per-stage output norms.

configure_label_conv [source] ¶

configure_label_conv() -> MLP

Build the MLP embedding the category one-hot for the global branch.

configure_propagations [source] ¶

configure_propagations() -> ModuleList

Build the per-stage feature-propagation modules interpolating stage features to every point.

PointM2AEPretraining [source] ¶

PointM2AEPretraining(
    in_channels: int,
    *,
    group_sizes: Sequence[int] = (16, 8, 8),
    num_groups: Sequence[int] = (512, 256, 64),
    mask_ratio: float = 0.8,
    encoder_depths: Sequence[int] = (5, 5, 5),
    encoder_dims: Sequence[int] = (96, 192, 384),
    token_local_channels: Sequence[int] = (128, 256),
    token_global_channels: Sequence[int] = (512,),
    local_radius: Sequence[float] = (0.32, 0.64, 1.28),
    decoder_depths: Sequence[int] = (1, 1),
    decoder_dims: Sequence[int] = (384, 192),
    decoder_up_blocks: Sequence[int] = (1, 1),
    num_heads: int = 6,
    drop_path: float = 0.1,
)

Bases: PretrainingModel

Implementation of the Point-M2AE pre-training model.

Point-M2AE: Multi-scale Masked Autoencoders for Hierarchical Point Cloud Pre-training. This implementation is adapted from the official repository ZrrSkywalker/Point-M2AE.

The model masks tokens at the coarsest stage, back-propagates the mask through the multi-scale grouping, encodes the visible tokens with the hierarchical encoder and reconstructs the masked local neighborhoods with a hierarchical decoder and a reconstruction head.

Parameters:

in_channels (int) –

The number of input channels (unused; coordinates drive the grouping).
group_sizes (Sequence[int], default: (16, 8, 8) ) –

The neighborhood size per stage.
num_groups (Sequence[int], default: (512, 256, 64) ) –

The number of centers per stage.
mask_ratio (float, default: 0.8 ) –

The fraction of coarsest-stage tokens to mask.
encoder_depths (Sequence[int], default: (5, 5, 5) ) –

The number of encoder blocks per stage.
encoder_dims (Sequence[int], default: (96, 192, 384) ) –

The encoder channel width per stage.
token_local_channels (Sequence[int], default: (128, 256) ) –

Hidden widths of the first-stage token embedder's per-point MLP.
token_global_channels (Sequence[int], default: (512,) ) –

Hidden widths of the first-stage token embedder's per-group MLP.
local_radius (Sequence[float], default: (0.32, 0.64, 1.28) ) –

The local-attention radius per stage (disabled during pre-training).
decoder_depths (Sequence[int], default: (1, 1) ) –

The number of decoder blocks per stage.
decoder_dims (Sequence[int], default: (384, 192) ) –

The decoder channel width per stage.
decoder_up_blocks (Sequence[int], default: (1, 1) ) –

The number of residual blocks in each feature-propagation stage.
num_heads (int, default: 6 ) –

The number of attention heads.
drop_path (float, default: 0.1 ) –

The maximum stochastic depth rate.

Shape

pos: \((N, 3)\)
batch: \((N,)\)
Output: a tuple (pred, target, pred_batch, target_batch): reconstructed and ground-truth neighborhood points, \((L \cdot k_0, 3)\) and \((L \cdot k_1, 3)\), each packed with the neighborhood index of its points.

Methods:

configure_h_encoder –

Build the hierarchical encoder with multi-scale back-propagated masking.
configure_h_decoder –

Build the per-stage decoder transformer blocks with a linearly scaled stochastic-depth schedule.
configure_decoder_pos_embeds –

Build the per-stage decoder positional-embedding MLPs.
configure_token_prop –

Build the feature-propagation modules upsampling decoder tokens between consecutive stages.
configure_rec_head –

Build the linear head predicting the coordinates of each masked finest-stage neighborhood.

configure_h_encoder [source] ¶

configure_h_encoder() -> HierarchicalEncoderMAE

Build the hierarchical encoder with multi-scale back-propagated masking.

configure_h_decoder [source] ¶

configure_h_decoder() -> ModuleList

Build the per-stage decoder transformer blocks with a linearly scaled stochastic-depth schedule.

configure_decoder_pos_embeds [source] ¶

configure_decoder_pos_embeds() -> ModuleList

Build the per-stage decoder positional-embedding MLPs.

configure_token_prop [source] ¶

configure_token_prop() -> ModuleList

Build the feature-propagation modules upsampling decoder tokens between consecutive stages.

configure_rec_head [source] ¶

configure_rec_head() -> Linear

Build the linear head predicting the coordinates of each masked finest-stage neighborhood.

HierarchicalEncoderMAE [source] ¶

HierarchicalEncoderMAE(
    encoder_depths: Sequence[int],
    encoder_dims: Sequence[int],
    local_radius: Sequence[float],
    num_heads: int,
    mask_ratio: float,
    drop_path: float = 0.1,
    token_local_channels: Sequence[int] = (128, 256),
    token_global_channels: Sequence[int] = (512,),
    act: Union[str, Callable, None] = "relu",
    act_kwargs: Optional[Dict[str, Any]] = None,
    norm: Union[str, Callable, None] = "batch_norm",
    norm_kwargs: Optional[Dict[str, Any]] = None,
)

Bases: Module

Hierarchical encoder variant used for pre-training, with multi-scale back-propagated masking.

The coarsest-stage mask is sampled and propagated to finer stages through the neighbor indices, so a fine token is visible only if it contributes to a visible coarse token. Visible tokens are packed per sample to the longest visible length and processed with a per-stage local-attention mask.

Parameters:

encoder_depths (Sequence[int]) –

The number of transformer blocks per stage.
encoder_dims (Sequence[int]) –

The channel width per stage.
local_radius (Sequence[float]) –

The local-attention radius per stage.
num_heads (int) –

The number of attention heads.
mask_ratio (float) –

The fraction of coarsest-stage tokens to mask.
drop_path (float, default: 0.1 ) –

The maximum stochastic depth rate.
token_local_channels (Sequence[int], default: (128, 256) ) –

Hidden widths of the first-stage token embedder's per-point MLP (later stages derive their widths from encoder_dims).
token_global_channels (Sequence[int], default: (512,) ) –

Hidden widths of the first-stage token embedder's per-group MLP.
act (Union[str, Callable, None], default: 'relu' ) –

The activation function used in the token embedders and transformer blocks.
act_kwargs (Optional[Dict[str, Any]], default: None ) –

Extra keyword arguments for the activation.
norm (Union[str, Callable, None], default: 'batch_norm' ) –

The normalization function used in the token embedders.
norm_kwargs (Optional[Dict[str, Any]], default: None ) –

Extra keyword arguments for the normalization.

Methods:

rand_mask –

Draw a random mask hiding mask_ratio of the coarsest-stage tokens, independently for every sample.

rand_mask [source] ¶

rand_mask(center: Tensor) -> Tensor

Draw a random mask hiding mask_ratio of the coarsest-stage tokens, independently for every sample.

Parameters:

center (Tensor) –

Token centers of shape \((B, G, 3)\).

Returns:

Tensor –

A boolean mask of shape \((B, G)\), True where the token is masked out.

local_attention_mask [source] ¶

local_attention_mask(mask: Tensor) -> Tensor

Convert a boolean neighbor mask into the additive pre-softmax bias of the shared attention.

Entries that are True (a point pair outside the local radius, or a padded / cross-sample pair) are pushed to a large negative value so they vanish after the softmax. The result is broadcast over the attention heads.

Parameters:

mask (Tensor) –

Boolean / float mask of shape \((B, N, N)\) where non-zero marks a forbidden pair.

Returns:

Tensor –

The additive attention bias of shape \((B, 1, N, N)\).

Shape

mask: \((B, N, N)\)
Output: \((B, 1, N, N)\)

local_att_mask [source] ¶

local_att_mask(
    pos: Tensor, radius: float, dist: OptTensor = None
) -> Tuple[Tensor, Tensor]

Compute the boolean local-attention mask of a center set from a pairwise-distance threshold.

A pair of centers is masked (True) when their Euclidean distance is at least radius. The pairwise-distance matrix is recomputed only when the cached dist does not match the current number of centers, so consecutive stages with the same token count share it.

Parameters:

pos (Tensor) –

Center coordinates of shape \((B, N, 3)\).
radius (float) –

The local-attention radius.
dist (OptTensor, default: None ) –

An optional cached pairwise-distance matrix from a previous call.

Returns:

Tensor –

A tuple (mask, dist) with the boolean mask of shape \((B, N, N)\) and the pairwise-distance
Tensor –

matrix of shape \((B, N, N)\).

Shape

pos: \((B, N, 3)\)
mask: \((B, N, N)\)
dist: \((B, N, N)\)

dense_centers_to_packed [source] ¶

dense_centers_to_packed(
    centers: Tensor,
) -> Tuple[Tensor, Tensor]

Flatten a densified center set \((B, G, 3)\) into packed coordinates and a batch index.

Every sample carries the same number of centers \(G\), so the packed batch index is simply each sample id repeated \(G\) times.

Parameters:

centers (Tensor) –

Densified center coordinates of shape \((B, G, 3)\).

Returns:

Tuple[Tensor, Tensor] –

A tuple (pos, batch) with pos of shape \((B \cdot G, 3)\) and batch of shape \((B \cdot G,)\).

Shape

centers: \((B, G, 3)\)
pos: \((B \cdot G, 3)\)
batch: \((B \cdot G,)\)

multi_scale_group [source] ¶

multi_scale_group(
    pos: Tensor,
    batch: Tensor,
    num_groups: Sequence[int],
    group_sizes: Sequence[int],
    random_start: bool = False,
) -> Tuple[List[Tensor], List[Tensor], List[Tensor]]

Build the multi-scale grouping by repeatedly applying FPS + KNN on the previous-stage centers.

Parameters:

pos (Tensor) –

Packed coordinates of shape \((N, 3)\).
batch (Tensor) –

Per-point batch index of shape \((N,)\).
num_groups (Sequence[int]) –

The number of centers per stage.
group_sizes (Sequence[int]) –

The neighborhood size per stage.

Returns:

List[Tensor] –

A tuple (neighborhoods, centers, idxs) of per-stage tensors. centers[i] is \((B, G_i, 3)\),
List[Tensor] –

neighborhoods[i] is \((B, G_i, k_i, 3)\) and idxs[i] is the flat neighbor index into stage \(i-1\).

point_m2ae

EncoderBlock [source] ¶

ConvResBlock1d [source] ¶

FeaturePropagation [source] ¶

HierarchicalEncoder [source] ¶

PointM2AEClassification [source] ¶

num_features property ¶

configure_h_encoder [source] ¶

PointM2AEPartSegmentation [source] ¶

num_features property ¶

configure_h_encoder [source] ¶

configure_label_conv [source] ¶

configure_propagations [source] ¶

PointM2AEPretraining [source] ¶

configure_h_encoder [source] ¶

configure_h_decoder [source] ¶

configure_decoder_pos_embeds [source] ¶

configure_token_prop [source] ¶

configure_rec_head [source] ¶

HierarchicalEncoderMAE [source] ¶

rand_mask [source] ¶

local_attention_mask [source] ¶

local_att_mask [source] ¶

dense_centers_to_packed [source] ¶

multi_scale_group [source] ¶

num_features `property` ¶

num_features `property` ¶
